Greenlee ESM Series Digital Multimeter DM-810A

Name: Greenlee ESM Series Digital Multimeter DM-810A
Brand: Greenlee
SKU: SKUkdaVV88RWz
Availability: InStock

Original price was: $258.00.Current price is: $132.89.

SKU: SKUkdaVV88RWz Categories: Power Tools, Voltage Testing & Measuring Tag: Greenlee Brand: Greenlee

Additional Details

Greenlee
ESM Series Digital Multimeter DM-810A
True RMS for no-compromise accuracy
Measures voltage; current;resistance; capacitance and frequency
Tests continuity and diodes
Backlit LCD with dual 10;000 count displays
BeepJack warns when test leads are incorrectly inserted in current measurement terminals
Automatic and manual range selection
Relative offset mode to see changes in measurements
Data hold
Use optional USB interface DMSC-9U for direct-To-PC logging
Lifetime limited warranty
Accessories included: (1)9V battery; bead temperature probe (DM-820A; DM-830A only; 400F/204C max); test leads; protective boot; carrying case
Amperage Measurement : 600; 6000A; 60; 600mA; 6; 10A
Battery : (1) 9 V
Capacitance : 60; 600nF; 6; 60; 600F; 6; 25 mF
Conductance : 99.99 nS
Display : Backlit LCD With Dual 10;000 Count
Frequency Measurement : 15Hz- 50kHz Sine Wave; 5Hz – 1MHz Logic Level Square Wave
Includes : (1) 9V Battery; Bead Temperature Probe (DM-820A; DM-830A Only; 400F/204C Max); Test Leads; Protective Boot; Carrying Case
Measurement Category : CAT IV; 1000 V
Replacement Part : TC-20 Carrying Case; TSG-3 Sure-Grip Test Leads; TPB Bead Temperature Probe (Included With DM-820A; DM-830A)
Resistance Measurement : 600O; 6; 60; 600 kO; 6; 60 MO
Standard : CAT IV; C/UL US Listed; TRUE RMS; CE Listed
Temperature Rating : K Type; -58 To 1832F (-50 To 1000C)
Type : Digital
Voltage Measurement : 60; 600 mV; 9.999; 99.99; 999.9 V

Manufacturer Specifications

Replacement Part	TC-20 Carrying Case, TSG-3 Sure-Grip Test Leads, TPB Bead Temperature Probe (Included With DM-820A, DM-830A)
Country of Origin	Taiwan
Conductance	99.99 nS
Included Components	(1) 9V Battery, Bead Temperature Probe (DM-820A, DM-830A Only, 400Â°F/204Â°C Max), Test Leads, Protective Boot, Carrying Case
Amperage Measurement	600, 6000Î¼A; 60, 600mA; 6, 10A
Frequency Measurement	15Hz- 50kHz Sine Wave, 5Hz – 1MHz Logic Level Square Wave
Temperature Rating	K Type, -58 To 1832Â°F (-50 To 1000Â°C)
Includes	(1) 9V Battery, Bead Temperature Probe (DM-820A, DM-830A Only, 400Â°F/204Â°C Max), Test Leads, Protective Boot, Carrying Case
Measurement Category	CAT IV, 1000 V
Voltage Measurement	60, 600 mV, 9.999, 99.99, 999.9 V
Capacitance	60, 600nF; 6, 60, 600Î¼F; 6, 25 mF
Display	Backlit LCD With Dual 10,000 Count
Battery	(1) 9 V
Standard	CAT IV, C/UL US Listed, TRUE RMS, CE Listed
Type	Digital
Resistance Measurement	600Î©; 6, 60, 600 kÎ©; 6, 60 MÎ©

Specifications

More Information
OPT SKU	GRDM-810A
MPN	DM-810A
UPC/GTIN	783310087434
Product Type	Voltage Testing & Measuring
Google Category	Hardware > Tools > Measuring Tools & Sensors > Electrical Testing Tools
Power Method	Cordless
Shipping Weight	3.00
